100g Shrimp Snack Chips Crispy Chips Corn Chips Weighing And Packaging Machine Vertical Form Fill Seal Packing Machine
1. Application:
Suitable for packaging many different kinds of products; such as puffy food, shrimp roll, peanut, popcorn, cornmeal, dried fruit, seed, small hardware,dumplings, vegetable, fruits and sugar etc.which shape is roll, slice and granule.
2. Technical parameter:
| Main machine parameter | LC-420 | LC-520 | LC-720 | LC-820 | LC-920 | LC-1050 |
| Speed | 10-50bag/min | 10-50bag/min | 10-40bag/min | 10-40bag/min | 10-40bag/min | 5-30bag/min |
| Bag-making size | (L)80-300mm* (W)80-200mm | (L)80-350mm (W)100-250mm | (L)100-500mm (W)160-350mm | (L)100-500mm(W)200-400mm | (L)100-500mm (W)220-450mm | (W)200-500mm (L)100-480mm, film pulling twice 800mm |
| Bag-making type | back sides sealing | back sides sealing | back sides sealing | back sides sealing | back sides sealing | back sides sealing |
| Filling range | 80-1000ml | 150-2000ml | 150-4000ml | 150-5000ml | 150-6000ml | 1000-10000ml |
| Max film width | 420mm | 520mm | 720mm | 820mm | 920mm | 1050mm |
| Film thickness(0.04-0.08) | 0.04-0.08mm | 0.04-0.08mm | 0.04-0.08mm | 0.04-0.08mm | 0.04-0.08mm | 0.06-0.12mm |
| Air consumtion | 0.3m³/min 0.65Mpa | 0.3m³/min 0.65Mpa | 0.3m³/min 0.65Mpa | 0.3m³/min 0.65Mpa | 0.3m³/min 0.65Mpa | 750L/min 0.6×105Pa |
| Power | 2.2KW/220V 50-60HZ | 2.5KW/220V 50-60HZ | 3KW/220V 50-60HZ | 3KW/220V 50-60HZ | 3KW/220V 50-60HZ | 7.5KW/220V 50-60Hz |
| Machine size | L1320*W950*H1360mm | L1430*W1200*H1700mm | L1716*W1260*H1820mm | L1854*W1440*H2019mm | L2014*W1574*H2095mm | 2100×1450×2600mm |
| Machine weight | 450kg | 400kg | 500kg | 600kg | 700kg | 900kg |
3. Technical characteristics:
1. PLC control with stable reliable biaxial high accuracy output and color touch screen, bag-making, measuring, filling, printing,cutting , finished in one operation.
2. Separate circuit boxes for pneumatic control and power control. Noise is low, and the circuit is more stable.
3. Film-pulling with servo motor double belt: less pulling resistance, bag is formed in good shape with better appearance, belt is resistant to be worn-out.
4. External film releasing mechanism: simpler and easier installation of packing film.
5. Adjustment of bag deviation just needed to be controlled by the touch screen. Operation is very simple .
6. Close down type mechanism , defending powder into inside of machine.
4. FAQ:
Q1: How to find a Packing machine suitable for my product?
To Longchuang distinguished customers and friends , in order to we have an accurate and efficient communication, please kindly consult us and provide following details as possible as you could .
1-Packing products:
2-Packing weight:
3-Dimension of the bag
4-Bag type:
5-Packing capacity:
If you have video or picture is very warm weclome.
For there are over 100 kinds of packing machine,different on bag sizes.
In order to recommend you the most suitable and best solution ,we need know these information.
Of course , if you are new and just start this business and don't have bag size , pls send us a sample picture or draft drawing)
, we can help you to find similar weight bag for your reference with our rich professional experience.
Q2: Can you send engineer service oversea?
Yes, and you need to pay some fee.
According to save your cost, we will send you a video of the installation of the machine.
Q3. How can we make sure about the machine's quality after we paid?
Before delivery, we will send you the pictures and videos of the machines.
And also you can visit our factory and test the machine.
Q4. We would like to have our own rand , is that ok ?
Yes, we accept OEM/ODM with your brand or your design.
Q5. Payment Method ?
1. 30% deposit, 70% before shipping.
2. We accept T/T, L/C etc.
Q6: Warranty
2 years for main parts after you received machines (Except the quick-wear parts)
Q7: About shipment:
You could designated freight logistics , we could also help for shipment by professionally .
5. Why Choose us ?
6. Machine picture
| Type large | 10-hopper scale |
| Maximum weighing | 10-2000g |
| Precision of weighing | 0.1-2g |
| Speed of weighing | 80 bags /minute |
| Power | 1000W Voltage: 220V |
| Gross weight | 271kg |
| Net weight | 220kg |
| Preset number of product | 10 kinds |
| Overall size(mm) | 1680(L)*1182(W)*1268H) |
Main feature:
(1) Range of application: dosing and weighing of small grain, powder material of daily food and condiment such as white sugar, salt, seed, rice, sodium glutamate, fodder, milk powder, coffee and sesame, etc.
(2) High precision data-type weighing sensor realizes precise weighing.
(3) Microcomputer control system with double vibration feeding and imported instrument; advanced technology and simple operation.
(4) Stainless steel sealed machine body; corrosion resistance and dust resistance.
(5) The measuring hopper can be disassembled rapidly; and it’s convenient in cleaning and maintenance.
(6) It can make different combination to enlarge weighing range according to customer’s requirements.
(7) With strong compatibility, it’s easy to be supported with other packing device.
7. Bag samples
8. Customer reputation
9. If you need more machine details and videos , pls contact us directly.
